Parametry produktu
28 let zkušeností s výrobou
Materiál: Rám: Plast (UL94-VO) Oběžné kolo:Plast (UL94-VO)
Napětí: 5VDC(4.0~5,5VDC),12VDC(6~13,8VDC),24VDC(12~27,6VDC)
Teplota: Provozní teplota: -10~70 stupňů (bez kondenzace)
Speciály: AS, RD, FG, PWM, Temperature Control, IP56
|
Modelka |
Napětí |
Proud |
Rychlost |
Objem vzduchu |
Statický tlak |
Hluk |
Hmotnost |
Křivka |
|||
|
V |
A |
RPM |
CFM |
m³/min |
mm-H20 |
Palce--H20 |
Pa |
dBA |
g |
||
|
LWAD6038LX-01 |
12 |
1 |
9500 |
52.1 |
1.48 |
25.4 |
1 |
249 |
57.3 |
90g |
① |
|
LWAD6038LH-02 |
12 |
0.8 |
8500 |
46.6 |
1.32 |
20.4 |
0.8 |
200 |
54.9 |
90g |
② |
|
LWAD6038LM-03 |
12 |
0.6 |
7500 |
41.2 |
1.17 |
15.9 |
0.62 |
155 |
52.2 |
90g |
③ |
|
LWAD6038LL-04 |
12 |
0.4 |
6500 |
35.7 |
1.01 |
11.9 |
0.47 |
117 |
49.1 |
90g |
④ |
|
LWAD6038LD-05 |
12 |
0.3 |
5500 |
30.2 |
0.85 |
8.5 |
0.34 |
84 |
45.5 |
90g |
⑤ |
|
LWAD6038MX-01 |
24 |
0.7 |
9500 |
52.1 |
1.48 |
25.4 |
1 |
249 |
57.3 |
90g |
① |
|
LWAD6038MH-02 |
24 |
0.5 |
8500 |
46.6 |
1.32 |
20.4 |
0.8 |
200 |
54.9 |
90g |
② |
|
LWAD6038MM-03 |
24 |
0.4 |
7500 |
41.2 |
1.17 |
15.9 |
0.62 |
155 |
52.2 |
90g |
③ |
|
LWAD6038ML-04 |
24 |
0.25 |
6500 |
35.7 |
1.01 |
11.9 |
0.47 |
117 |
49.1 |
90g |
④ |
|
LWAD6038MD-05 |
24 |
0.2 |
5500 |
30.2 |
0.85 |
8.5 |
0.34 |
84 |
45.5 |
90g |
⑤ |
|
LWAD6038HX-01 |
48 |
0.4 |
9500 |
52.1 |
1.48 |
25.4 |
1 |
249 |
57.3 |
90g |
① |
|
LWAD6038HH-02 |
48 |
0.28 |
8500 |
46.6 |
1.32 |
20.4 |
0.8 |
200 |
54.9 |
90g |
② |
|
LWAD6038HM-03 |
48 |
0.2 |
7500 |
41.2 |
1.17 |
15.9 |
0.62 |
155 |
52.2 |
90g |
③ |
|
LWAD6038HL-04 |
48 |
0.15 |
6500 |
35.7 |
1.01 |
11.9 |
0.47 |
117 |
49.1 |
90g |
④ |
|
LWAD6038HD-05 |
48 |
0.12 |
5500 |
30.2 |
0.85 |
8.5 |
0.34 |
84 |
45.5 |
90g |
⑤ |
